1 Piece (MOQ)

Business Type Manufacturer, Exporter
Brand Name VSI
Test Modes Optical Rotation, Sugar Degree
Measurement Range +/- 70 Deg. (Optical Rotation) +/- 200 Deg.Z (Sugar)
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Accuracy
+/- 1 Deg. (Full Scale)
Resolution
0.01 Deg.
Display
128x64 Graphical LCD
Keys
4-Keys for Menu Operation
Calibration Mode
2 Point (Zero & Span)
Interface
USB
RTC
In-built clock with date and time display
Data Storage Capacity
1000 Logs with Date & Time
Power Supply
230V +/- 10%, 50 Hz AC
Product Code
VSI-740

VSI Electronics Private Limited is an established manufacturer, supplier and exporter of Digital Automatic Polarimeter from India. Digital Automatic Polarimeter offered by the company are high on quality, performance and are made of the finest quality raw materials, making them durable and long lasting.

Digital Automatic Polarimeter (VSI-740) advanced digital circuit and microcontroller based, graphical LCD display, storage of three times result for Re-M (Repetition Measurement) and calculation of averages value measurement of dark-colored samples. USB interface.  Measurement range -70 Deg. to +70 Deg. (optical rotation) and -200 Deg. to +200Deg.Z (sugar scale).  Most suitable for sugar content measurements.



SALIENT FEATURES

  • Microprocessor Based
  • User Friendly and Menu Driven Software
  • 128x64 Graphical LCD
  • Two Point Calibration
  • USB Interface
  • USB Port for interfacing the system with PC
  • One can see the stored logs on the system  before printing
  • Internal storage capacity of 1000 logs with date and time
  • Note: Appearance & Specifications are subject to change due to continuous development.



Digital Automatic Polarimeter (VSI-750) advanced digital circuit and microcontroller based, large display, storage of 3 times result for Re-M (Repetition Measurement) and calculation of average value measurement of colored samples. RS-232 interface.  Measurement range -45 Deg C to + 45Deg C, -120 Deg C  to +120Deg C Most suitable for sugar industries for sugar content measurements

Note: Appearance & Specifications are subject to change due to continuous development.

Yes! I am interested


Technical Specification of Digital Automatic Polarimeter: VSI-750

Test Modes Optical Rotation, Sugar Degree
Light Source LED
Wavelength 589.44 nm.
Measurement +/- 45 Deg. (Optical Rotation) +/- 120 Deg.Z (Sugar)
Minimum Indicating Value 0.001 Deg. (Optical Rotation) 0.01 Deg.Z (Sugar)
Accuracy +/- (0.01 + Measurement Value x 0.05%) Deg.Z (Optical Rotation)
Repeatability +/- (0.03 + Measurement Value x 0.05%) Deg.Z (Sugar)
Display LCD
Test Tube 200mm, 100mm
Sample Transmittance >1%
Interface RS232
Operation Voltage 220V +/- 10%, 50 Hz AC
Software Yes
Overall Dimensions 730 x 480 x 470mm
Weight (Gross) 36 Kg.
STANDARD ACCESSORIES Sample Tubes 100mm, 200mm., Software Kit: RS232 Cable, Software CD, Main Lead, Fuse and Instruction Manual.
